1.4301 stainless steel, also known as 304 stainless steel, is a widely used austenitic stainless steel, a general-purpose stainless steel.
1.4301 Stainless Steel Plate Specification
Thickness: 0.3-200mm
Width: 1000mm,1250mm,1500mm,2000mm, etc
Length: 2000mm, 2438mm, 3000mm, 5800mm, etc
Standard: ASTM A240, EN 10088-2, etc
1.4301 stainless steel, also known as 304 stainless steel, is a widely used austenitic stainless steel, a general-purpose stainless steel, with excellent corrosion resistance, good formability, machining properties and welding properties, widely used in various industries.
We procure 1.4301 plate directly from leading stainless steel mills (Baosteel, TISCO, etc.), adopt high-quality base steel (e.g. Baosteel, Shougang) and have ISO/BV/SGS certification, ensuring consistent material.
Our plates strictly comply with ASTM A240 and EN 10088-2 standards (DIN 1.4301,X5CrNi18-10). We control flatness and dimensions to tight tolerances within ± 0.2 mm, to ensure that each roll (plate) is standard 18Cr-8Ni (304) grade uniform thickness and flatness.
| Grade | 1.4301,304 |
| Thickness | 0.3-200mm |
| Length: | 2000mm, 2438mm, 3000mm, 5800mm, 6000mm, 12000mm, etc |
| Width | 40mm-600mm, 1000mm, 1250mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Standard | ASTM 240, EN 10088,JIS,DIN,AISI,GB |
| Surface | BA,2B,NO.1,NO.4,4K,HL,8K,Embossed,Color,or as required |
| Certification | ISO, SGS, BV |
| Technique | Cold Rolled, Hot Rolled |
| Edge | Mill Edge / Slit Edge |
| Element | % Present |
| Carbon (C) | 0.0 – 0.07 |
| Chromium (Cr) | 17.50 – 19.50 |
| Manganese (Mn) | 0.0 – 2.00 |
| Silicon (Si) | 0.0 – 1.00 |
| Phosphorous (P) | 0.0 – 0.05 |
| Sulphur (S) | 0.0 – 0.03 |
| Nickel (Ni) | 8.00 – 10.50 |
| Nitrogen (N) | 0.0 – 0.11 |
| Iron (Fe) | Balance |
| Property | Value |
| Tensile Strength(Mpa), Rm | 625 |
| Yield Strength (Mpa),Rp 0.2 | 315 |
| Density | 8.00 g/cm³ |
| Melting Point | 1450 °C |
| Thermal Expansion | 17.2 x10^-6 /K |
| Modulus of Elasticity | 193 GPa |
| Thermal Conductivity | 16.2 W/m.K |
| Electrical Resistivity | 0.072 x10^-6 Ω .m |
| Elongation | 45 |
| Standard | UNS | WERKSTOFF NR | AFNOR | EN | JIS | BS | GOST |
|---|---|---|---|---|---|---|---|
| SS 304 | S30400 | 1.4301 | Z7CN18-09 | X5CrNi18-10 | SUS304 | 304S31 | 08Х18Н10 |
1. Exceptional Corrosion Resistance:
2. Superior Formability and Weldability:
3. Non-magnetic (almost non-magnetic under annealed conditions, may be weakly magnetic after cold work)
4. Excellent low temperature performance (for low temperature scenarios)
5. Low thermal conductivity, medium electrical conductivity
Surface Finish
We offer finishes from bright annealed (BA, No.1) to cold-rolled (2B), No.4, HL and mirror (8K).With advanced polishing equipment and strict quality control, we can provide flat and clean plates without scratches and burrs.Whether for decorative materials or mechanical parts, we fulfil high standard.
Processing Services
We can cut plates to any size or shape, mill or polish edges, flatten, chamfer, polish or apply protective PVC film and other secondary processing according to requirements, and label or laser-mark per request.
For export shipments, we use standard seaworthy packaging (bundled in wooden crates/pallets with waterproof wrapping).
With sufficient stock and flexible production capacity, we can deliver on time and provide exclusive technical support for customized projects.
Application
When selecting 1.4301 stainless steel plate, the following environments should be avoided:
Complete control over products allows us to ensure our customers receive the best quality prices and service. Contact us for a free quote,JBLSTEEL will provide the right solution for your project.
We warmly welcome you to visit our company anytime. I believe our product quality, professional service and competitive price will satisfy you. We look forward to cooperating with you.
