The quotations for Q960 series steel plates (Q960C, Q960D, Q960E, Q960F) are influenced by various factors, including raw material costs, production processes, and market demand.
Thickness： 4mm~150mm
Width：1500mm~4000mm
Length：3000mm~25000mm
Choose JBL Stainless, for the best value for money.
Q960 High-strength plates are renowned for their high strength and wear resistance, and are suitable for applications in construction machinery, building structures, and other fields. Besides the material properties, it is even more important to control the cost reasonably!
By using the Q960 series steel plate Q960C, Q960D, Q960E, Q960F, not only can the structural safety be enhanced, but also the material cost can be reduced. This is because kekuatan tinggi means that less material can be used to achieve the same load-bearing effect.
Quend 960—–Advantages
Q960 steel —Size
Density of Q960 steel：7.85 t/m3
Example：Q960 16mm×2000mm×8000mm t=16, B=2m, L=8m W=16×2×8×7.85=2009.6 kg
The boom/bracket of the heavy-duty crane / The frame/cab of the large mining dump truck / The arm of the concrete pump truck / The roadway support in the shaft and tunnel / The roadway support in the tunnel / The local structure of the bridge / The cable anchoring structure of the large-span bridge / The truss node / The television tower / The transmission tower / The gates/operating machines of the large hydropower station / The turntable/base of the heavy machinery / The partial components of the offshore platform.
Q960 High-strength Plate Chemical Elements:
S960 High Strength Steel Plates Mechanical Properties:
S960 High Strength Steel Plates price is how much?
The price of high-strength plates is affected by thickness, specification and purchase quantity. For regular thickness plates (8-50mm), the market price is approximately 5,000 – 8,000 yuan per ton. The exact price will depend on the actual size and specific requirements for customization.
Q960: Suggestions for selecting high-strength steel?
If you plan to use it for a long term, you can sign a long-term contract with the supplier JBLstainless to lock in the price; for small-scale purchases, it is recommended to compare quotations from multiple suppliers to avoid hidden costs.
| mark | quality grade | Impact test temperature | Minimum impact energy (longitudinal) | Characteristics of applicable scenarios |
|---|---|---|---|---|
| Q960C | C | 0℃ | ≥34J | Structural components for normal temperature or mild climate |
| Q960D | D | -20℃ | ≥34J | General low-temperature environments (such as northern winters） |
| Q960E | E | -40℃ | ≥34J | Cold regions, important load-bearing structures |
| Q960F | F | -60℃ | ≥47J | Extremely cold environment, key safety components |
Why choose JBL Stainless’ S960QL Steel Plates?
JBL Stainless Q960 high-strength steel plates are available in a wide range of specifications, with sufficient inventory. They come with original factory warranty certificates. We offer 24-hour rapid quotations and on-site pick-up services. “Huahu Steel Group” has a one-tenth-of-a-million-ton inventory of ready-to-use products. As a 20-year veteran in the steel industry, it enjoys a good reputation and has received unanimous praise from the market over the past 20 years!
Compared with ordinary steel, Q960 has significant advantages:
Which type of high-strength steel should be preferred for construction?
Q960
Q960: What are the key points to be noted during the use of high-strength steel?
It is important to pay attention to the processing and welding techniques of the high-strength S960QL structural steel to ensure that its performance can be fully utilized. At the same time, proper maintenance and care can also extend its service life.
What is Q960?
Q960 is a type of high-strength low-alloy steel (HSLA). The “Q” in its name stands for the pinyin initials of “yield point” (Quenching), and the number “960” indicates that the minimum yield strength of this steel is 960 MPa.
What do the letters C/D/E/F in Q960 mean?
Classification of quenched and tempered steel grades: Q960C, Q960D, Q960E, Q960F. The letters “C/D/E/F” represent the quality grades of the steel plates, with C being the lowest and F being the highest. “C/D/E” indicates the impact temperature: Q960C = 0-degree impact test; Q960D = -20-degree low-temperature impact test; Q960E = -40-degree low-temperature impact test.
Which foreign brands does Q960 correspond to?
Europe (EN): S960Q (corresponding to Q960D, -20℃ impact), S960QL (corresponding to Q960E, -40℃ impact); Some materials mention that S960QL1 is of a higher toughness grade.
USA (ASTM): Approximately ASTM A514 Gr. B or Gr. Q (with reference to the A1018 series of high-strength steel.
Brand name and grade: SSAB Weldox 960, products of the same strength level from the Hardox series.
What are the differences between Q960 and Q890, Q960, and Q1100?
Q890, Q960, and Q1100 are all quenched and tempered ultra-high strength structural steels. The main difference lies in the varying yield strength levels (≥890/960/1100 MPa respectively), which in turn affect the tensile strength, applicable thickness, low-temperature toughness requirements, and typical application scenarios.
What are the differences between Q960 and ordinary Q355 steel plates?
Q960 is a quenched and tempered ultra-high strength steel with a yield strength of ≥ 960 MPa, while Q355 is a conventional low-alloy high-strength structural steel with a yield strength of ≥ 355 MPa (decreasing with thickness).
Q960 is classified as high-strength steel or ultra-high-strength steel?
Q960 falls under high-strength steel (high-strength structural steel), but does not fall under the ultra-high-strength steel category as defined in the general engineering context.
What are the differences in chemical composition of Q960 produced by different steel mills?
As the Q960 high strength steel specific components are classified as trade secrets and process formulas of each steel mill, the publicly available information can only provide the national standard upper limit.
Kontak JBL Stainless Company and expect a prompt response.
Q960 Why is the strength so high?
The Q960 High Strength Steel Sheet is attributed to the synergy of its low-carbon microalloying composition design and the tempering (quenching + tempering) heat treatment process. Through solid solution strengthening, precipitation strengthening, fine grain strengthening and martensitic structure transformation, the yield strength of Q960 reaches ≥ 960 MPa.
Does higher strength in Q960 imply lower toughness?
Q960 Pressure Vessel Plate Meeting Strength Standards Does Not Mean Poor Toughness.
Q960 What defects are likely to occur during the production process?
Q960 Alloy Plate core defects in production include central segregation/porosity, non-metallic inclusions (especially TiN), gas-induced white spots/holes, microcracks and delamination caused by improper post-rolling cooling.
Will the properties of Q960 change after processing?
Q960 High Strength Steel Plate undergoes changes in performance after processing, and the key factor lies in the type of processing.
Can Q960 replace Q690?
TIDAK
What are the differences in application between Q960 and NM wear-resistant plates?
Q960 is an ultra-high-strength structural steel, mainly used for the load-bearing framework and weight reduction design; the NM series is a special wear-resistant steel, mainly used for anti-corrosion liners and protection of vulnerable components. The performance orientation and application scenarios of these two are fundamentally different.
How can one determine the quality of Q960?
To determine the quality of Quend 960 extra high strength structural steel, it is necessary to refer to the third-party test report and the steel mill’s quality guarantee certificate.
Kontrol penuh atas produk memungkinkan kami untuk memastikan pelanggan kami menerima harga dan layanan dengan kualitas terbaik. Hubungi kami untuk penawaran gratis, JBLSTEEL akan memberikan solusi yang tepat untuk proyek Anda.
