Stainless steel composite plate is a leading-edge material,consisting of a stainless steel outer layer (or cladding) and a carbon steel base material (or substrate),combine excellent corrosion resistance, wear resistance, and non-magnetic properties of stainless steel with good weldability, formability, deep-drawing properties, and thermal conductivity of carbon steel.
Material:
304 + Q235B;
316L + Q345R;
Q235B + 2205;
Q235B + 316L
Our Stainless steel composite plate offers the rugged strength of carbon steel with the premium corrosion resistance of 304/316L/Duplex stainless steel. Engineered for pressure vessels, storage tanks, and chemical reactors. Meet ASME, ASTM standards with our bimetal composite technology. Save up to 50% on material costs for pressure vessels & storage tanks.
| Feature | Solid Stainless Steel | Composite Steel Plate |
|---|---|---|
| Cost | 100% (High Investment) | Save 30% – 50% |
| Corrosion Resistance | Excellent | Identical Performance |
| Strength | Moderate | Superior (Carbon Steel Core) |
| Shear Strength | / | ≥ 210 MPa (Exceeds ASTM) |
Budget Affordable:
Reduce material costs by 30%-50% without compromising safety;
Superior Strength:
Benefit from the mechanical strength of carbon steel and the anti-corrosion of stainless steel;
Design Flexibility:
Fully customizable thicknesses for both base and cladding layers.
Cladding Material: SS 304, 304L, 316, 316L, 321, Duplex 2205/2507
Base Material: Q235, Q355 – Q690, Q245R, Q355R, Q355QL
Thickness: 4～35mm, 4.5mm-55mm,or customized
Width: 1000～2300mm, 1300mm-2800mm
Length: 3000mm-14000mm, can be customized
Bonding Technology: Explosive Bonding & Hot Rolling.
Bonding Grade: 100% Ultrasonic Testing (UT) Grade A / Grade B
Petrochemical & Oil Gas:
Desalters, Storage Tanks, Refinery Columns;
Chemical Processing:
Pressure Vessels, Heat Exchangers, Reactors;
Water Treatment:
Desalination Plants, Pipelines.
Power & FGD:
Chimney Liners, FGD Systems.
Raw Material Inspection: Chemical & mechanical properties verify.
Bonding Integrity: 100% Ultrasonic Testing (UT).
Mechanical Testing: Tensile, Bend, and Shear testing.
Surface Treatment: Pickling, Polishing, or Sandblasting.
Certification: Full MTC (Mill Test Certificate) provided with every shipment.
It offers a significant cost reduction (up to 50%) while maintaining the same corrosion resistance on the surface. The carbon steel base provides superior structural strength and weldability for heavy industrial applications.
We can provide cladding layers as thin as 0.5mm or as thick as 15mm, depending on your project requirements.
Complete control over products allows us to ensure our customers receive the best quality prices and service. Contact us for a free quote,JBLSTEEL will provide the right solution for your project.
